IP 68 tester

The ip68 tester is used to test product shell’s tightness about waterproof and dustproof performance complying to IEC 60529 standard. As the first characteristic number "6" stands for complete protection from dust, and "8" as the second characteristic number stands for continuous immersion in water under certain conditions to maintain the normal operation of the equipment.



Model: DI-800, DI-1000, DI-1500, DI-2000, R78-600

Standard: IEC 60529, IP5X, IP6X,  ISO20653,  IEC 60068-2-68,  IEC 60598, MIL-STD-810G, GJB 150.8-86, ISO 20653, IEC 60529, UL 50E, UL 1598, UL 153,  UL1573, UL 60950-1, IPX8




Features and Benefits of IP68 Tester - IP6X Dustproof Tester

1. The inner workroom is made of 304 stainless steel, with good corrosion resistance and strength, and can withstand the erosion of talc powder and other dust for a long time to ensure the service life of the ip68 tester.




2. The door is equipped with observation window, which is safe and reliable, convenient to observe the status of the sample in the ip68 tester when the dust blows.




3. The use of double-wire silicone rubber sealing strip, and equipped with electromagnetic lock, can effectively prevent dust leakage and misoperation, ensure the sealing environment inside the test chamber, meet the dustproof requirements of IP6X class.




4. The touch controller can control the dust blower, dust vibration and the total test time, and has the functions of setting the dust blowing time (stop, blow) continuously or periodically, automatically alternating the vibration time, and presetting the test time.





Specifications of IP68 Tester - IP6X Dustproof Tester

Model

DI-800

DI-1000

DI-1500

DI-2000

Internal Dimension (mm)

800*1000*1000

1000*1000*1000

1000*1500*1000

1000*2000*1000

Overall Dimension (mm)

1040*1450*1960

1330*1450*1960

1330*1950*1990

1330*2450*1990

Useful Volume (L)

800

1000

1500

2000

Temperature Range

Ambient ~ +50℃

Humidity Range

< 30% RH

Normal Wire Diameter

50um

Nominal Width of a Gap Between wires

75um

Fight Time

0 ~ 99H59M

Blowing Time

0 ~ 99H59M



Configuration of IP68 Tester - IP6X Dustproof Tester


①Vacuum pump

Through pumping, a certain vacuum degree is formed inside the test chamber or inside the sample, which simulates the changes in air pressure that the product may face in actual use, and the possibility of sand and dust entering in the low pressure environment, and promotes the flow and circulation of sand and dust.



②Vacuum filter

 Filter the gas entering the vacuum pump, prevent the dust particles in the test chamber from entering the vacuum pump, and reduce the dust residue in the internal circulation system of the test chamber.



③Circulating fan

 Generate air flow, promote the dust circulation, ensure that the dust can fully contact all parts of the sample, so that the dust distribution in the test box is more uniform, simulate the exposure of the product in the actual dust environment.



④Vibrating motor

 By shaking the inside of the test chamber, the sand attached to the surface of the sample or the wall of the test chamber can be shed, so as to avoid the accumulation of sand in some parts and affect the accuracy of the test results.



Vertical circulation air blows dust to the workroom, forming a dust circulation system.



Features and Benefits of IP68 Tester - IPX8 Water Immersion Tester

1. High quality sealing locks, to ensure the sealing performance of the ip68 tester during the process of pressurization and flooding, to prevent water leakage.




2. The internal pressure can be accurately controlled to simulate the water pressure environment under different water depths of 1-50m with pressure up to 50bar. Built-in sample holder whose maximum load 50 kg, and the height is adjustable.






3. The installation of safety valves, pressure sensors and other devices, when the internal pressure exceeds the set safety range, automatically release the pressure or stop the pressure.




4. Quickly discharge the water and release the pressure in the tester after the test, convenient for taking out the sample and conducting the next test.






Specifications of IP67 Test Equipment - IPX8 Water Immersion Tester

Model

R78-600

Internal Dimensions (mm)

Diameter600*Height1500

Overall Dimensions (mm)

Diameter800*Height1800

Pressure

50m water depth pressure

Open Mode

Pneumatic lid

Material

A3 steel plate,wall thickness 15mm

Water Supply System

Storage water tank,Automatic water supply



Configuration of IP68 Tester - IPX8 Water Immersion Tester





LIB can build a variety of personalized IP LABS according to your needs, and provide one-stop services for design, commissioning, installation, and after-sales. Tell us your needs, we provide you with professional solutions and the best quotes.
