Accurate humidity measurement is essential in industries such as pharmaceuticals, food storage, electronics, and meteorology. Hygrometers play a key role, and their reliability directly affects product quality and compliance.
Maintaining accurate readings requires regular verification. Many laboratories and industrial users face challenges like unstable conditions, uneven humidity, and inconsistent results, which can reduce confidence in calibration data.
LIB industry offers high-quality climatic test chambers that provide controlled temperature and humidity, ensuring stable and repeatable hygrometer calibration for industrial and laboratory applications.
Not all environmental chambers are designed for calibration purposes. Standard chambers may meet general testing needs, but they often fall short when used for hygrometer verification.
LIB industry climatic chambers address these limitations:
In standard climatic test chambers, temperature and humidity may vary across the workspace. LIB industry chambers use advanced airflow design to ensure uniform distribution.
Impact:
All hygrometers experience the same conditions, providing consistent and comparable readings.
Humidity and temperature may drift over time in conventional systems. LIB industry climatic chambers maintain controlled environmental conditions with a humidity deviation of ±2.5% RH and temperature fluctuation of ±0.5°C.
Impact:
Reliable, repeatable conditions reduce calibration errors and improve testing confidence.
Standard chambers often take longer to reach target conditions. LIB industry chambers are designed with efficient heating, cooling, and humidification systems to reach setpoints quickly and maintain them consistently.
Impact:
Shorter calibration cycles, improved workflow efficiency, and reduced operator intervention.
A climatic test chamber from LIB industry provides a controlled, stable, and repeatable environment for industrial hygrometer verification. Key features include:
| Name | Temperature Humidity Chamber | ||||
Temperature range | -20℃ ～+150 ℃ | |||||
Low type | A: -40℃ B:-70℃ C -86℃ | |||||
Humidity Range | 20%-98%RH(Option） | |||||
Temperature deviation | ± 2.0 ℃ | |||||
Heating rate | 3 ℃ / min | |||||
Cooling rate | 1 ℃ / min | |||||
Controller | Programmable color LCD touch screen controller, Multi-language interface, Ethernet , USB | |||||
Refrigerant | R404A, R23 | |||||
Exterior material | Steel Plate with protective coating | |||||
Interior material | SUS304 stainless steel | |||||
Standard configuration | 1 Cable hole (Φ 50) with plug; 2 shelves | |||||
Timing Function | 0.1~999.9 (S,M,H) settable | |||||
|
|
|
| |
| Robust Workroom | Cable Hole | Temperature and Humidity Sensor | PID controller |
Temperature range: -20°C to +150°C
Humidity range: 20% RH to 98% RH
Humidity deviation: ±2.5% RH
Temperature fluctuation: ±0.5°C
LIB industry chambers maintain stable conditions suitable for industrial verification and routine calibration, ensuring consistent test results.
To meet various application needs, LIB industry offers two humidity measurement methods:
Wet-bulb method (gauze type): Reliable and resistant to long-term drift.
Capacitive sensor: Fast response, low maintenance, and easy operation.
Users can choose the appropriate method depending on calibration requirements, maintenance preferences, and test standards.
LIB industry chambers feature advanced airflow systems to ensure:
Temperature uniformity: ≤ ±2.0°C
Humidity uniformity: ≤ ±2.5% RH
Result:
All hygrometers in the chamber experience uniform environmental conditions, ensuring consistent calibration results.
The intelligent controllers of LIB industry chambers enable:
Multi-step temperature and humidity programming
Automatic cycling and dwell time control
Real-time monitoring and data logging
Optional communication interfaces (RS485, Ethernet) allow integration with external data acquisition systems.
Benefits:
Highly repeatable test conditions
Reduced operator intervention
Improved calibration efficiency
LIB industry chambers support a broad operating range, allowing:
Low humidity: down to 20% RH (with optional dry air system)
High humidity: up to 98% RH
Combined temperature-humidity testing
This ensures calibration can cover multiple points across real operating environments, including extreme humidity conditions.
LIB industry chambers are designed for practical laboratory and industrial use, featuring:
Heated observation window to prevent condensation
Multiple cable ports (Ø50 mm / Ø100 mm optional) for sensor connections
Stainless steel interior for durability and easy cleaning
Touch-screen interface for intuitive operation
Advantage:
Easy setup for multiple hygrometers, simple connection to reference instruments, and real-time observation without disturbing test conditions.
LIB industry offers fully customizable climatic chambers to match specific calibration requirements:
Chamber size customization (bench-top or floor-standing) Benchtop Environmental Chamber Reach-in Temperature and Humidity Test Chamber
Multi-sensor mounting racks for batch calibration
Programmable test profiles for automated workflows
Data acquisition and communication interfaces (Ethernet, RS485)
Remote monitoring and control
Every system is tailored to ensure stable and repeatable conditions, optimizing calibration efficiency.
LIB industry temperature humidity chambers support regulated environments with features including:
ISO/IEC 17025 laboratory compliance
Data recording and traceability
Optional audit trail software (CFR 21 Part 11 readiness)
These capabilities help ensure calibration processes are well-documented and repeatable, providing confidence in test results.
Selecting the right chamber depends on application and accuracy needs:
Routine verification
Quality control
Comparative testing
Number of hygrometers to calibrate simultaneously
Available lab space
| Application Type | Required Accuracy | Recommended Solution |
|---|---|---|
| Industrial Verification | ±2% – ±3% RH | LIB industry Climatic Chamber |
| Laboratory Calibration | ±0.5% – 1% RH | Precision Calibration System |
| Reference Calibration | < ±0.5% RH | Metrology Equipment |
Industrial Hygrometer Calibration vs. Reference Calibration
It is important to distinguish between calibration levels:
Reference Calibration: Conducted in national metrology institutes using highly specialized systems.
Industrial Calibration / Verification: Conducted in laboratories, production sites, or quality control environments using LIB industry climatic chambers.
Purpose of Industrial Verification:
Routine performance verification
Batch comparison of sensors
Consistency checks
LIB industry climatic test chambers provide a cost-effective, reliable, and practical solution for these scenarios.LIB industry humidity chambers are optimized for industrial verification and consistency testing.
LIB industry climatic test chambers are widely used in:
Calibration laboratories
Manufacturing quality control
Meteorological stations
Pharmaceutical storage validation
Food and logistics environments
Electronics and component testing
Tell us your:
Number and size of hygrometers to be calibrated
Required temperature and humidity range
Calibration or verification standards (if applicable)
Testing method preference (wet-bulb or capacitive sensor)
LIB industry engineers will provide a tailored solution within 24 hours.
Humidity Deviation ±2.5% RH for stable and reliable verification
Custom Calibration Solutions
3-Year Warranty Lifetime Technical Support to ensure continuous performance
Professional English-Speaking After-Sales Team
5×12 Hour Fast Response to minimize downtime
4 Global Service Centers covering Europe, America, Southeast Asia, and Central Asia
30+ Global Agents providing localized support worldwide
Avoid inconsistent results, repeated calibration cycles, and unnecessary downtime caused by unstable environments or unsuitable equipment.
Contact LIB industry now to get your customized climatic test chamber for reliable hygrometer calibration and verification.
