Tabletop Environmental Chamber

Tabletop environmental chamber is small suitable for small parts or samples, can simulate various temperature and humidity, test product performance and stability.

There are three types of temperature ranges, -20 ° C, -40 ° C, -60 ° C to 150 ° C, with temperature fluctuations within ±0.5 ° C. The humidity range is 20%-98% RH, and the humidity deviation is about ±3% RH.


Model: TH-50A ,TH-50B, TH-50C

Standard: AAMA501, ASTM D4169-16, IEC 61215, IEC 61646, IEC61108, IEC62688, MIL-STD-811D

窗体顶端



窗体底端


Features and Benefits of Tabletop Environmental Chamber

1. Due to its small size and lightweight design, it is relatively convenient to move and handle, and the placement position can be adjusted at any time according to needs to meet the test requirements in different scenarios.



2. The energy consumption is lower than that of large test equipment, and long-term use can save energy costs and meet the use requirements of places with limited power supply.



3. The internal volume is small, suitable for the test of smaller samples or a small number of samples.



4. Tabletop environmental chamber is mainly used to simulate specific environmental conditions, such as temperature, humidity, conventional constant temperature and humidity or other specific environmental tests.



Specifications of Tabletop Environmental Chamber

Model

TH-50

TH-80

Internal Dimension (mm)

320*350*450

400*400*500

Overall Dimension (mm)

820*1160*950

900*1210*1000

Interior Volume

50L

80L

Heat load

1000W

Temperature Range

A : -20℃ ~ +150 ℃

B : -40℃ ~ +150 ℃

C: -70℃ ~ +150 ℃

Temperature Fluctuation

± 0.5 ℃

Temperature Deviation

± 2.0 ℃

Humidity Range

20% ~ 98% RH

Humidity Deviation

± 2.5% RH

Cooling Rate

1 ℃ / min

Heating Rate

3 ℃ / min

Cooling system

Mechanical compression refrigeration system

Controller

Programmable color LCD touch screen controller

Ethernet connection

Safety Device

Humidifier Dry-combustion protection; Over-temperature Protection; Over-current Protection;

Refrigerant High-pressure protection; Water Shortage Protection; Earth leakage Protection

Exterior Material

Steel Plate with protective coating

Interior Material

SUS304 stainless steel

Thermal Insulation

Polyurethane foam and insulation cotton

Observation Window

Interior lighting, double-layer thermo stability silicone rubber sealing

Standard Configuration

1 Cable hole (Φ 50,) with plug; 2 shelves

Weight

190kgs

220kgs


Configuration of Tabletop Environmental Chamber


① Workroom

  • 50L,80L size optional.

  • Workroom is made of SUS 304 stainless steel, corrosion resistance, high and low temperature resistance, easy to clean.

  • Double punched sample holder, adjustable height, bearing capacity 50KG.



 Control system

The core component of the test chamber, responsible for setting and adjusting the temperature, humidity and other parameters.



 Air circulation system

Composed of :

  • Fan:

    Used to circulate the air inside the test chamber to make the temperature, humidity and other environmental parameters inside the test chamber more uniform.

  • Ventilation duct:

    connecting the fan and the inside of the test chamber to transport air.


④ Heating system

Using resistance wire heating, heating speed is fast, stable performance.tabletop_environmental_chamber9.jpg

⑤ Water system

Steam humidification converts water into steam and transmits it to the inside of the test chamber.


⑥ Cooling system

Compressor refrigeration. It is composed of compressor, condenser, evaporator and throttling device.
