IEC 60529 IP4X Test Probe D

The LIB Industry IEC 60529 IP4X Test Probe D is engineered to verify protection against access to hazardous parts through hazardous wire insertion. Manufactured in accordance with IEC 60529 requirements, this probe incorporates a calibrated 1N thrust spring system to ensure accurate force application during IP4X safety testing of electrical enclosures, household appliances, and automotive components.

Designed for reliable and repeatable testing, the LIB Industry IP4X Test Probe D features a 1.0 mm probe diameter, 100 mm probe length, and 35 mm dam-sphere diameter, providing a practical solution for IP4X ingress protection verification.


Key Highlights of IEC 60529 IP4X Test Probe D

Precise Force Control:

Built-in 1N thrust mechanism ensures full compliance with standard force limits.

Premium Stainless Steel:

High-rigidity 1.0mm probe wire prevents bending during testing.

Insulated Handle:

Ergonomic non-slip nylon handle for safe operation.

Hazardous Access Test:

Designed to verify protection against access to hazardous parts with a wire.


Technical Specifications of IEC 60529 IP4X Test Probe D

Parameter

Specification

Product Name

IP4X Test Probe D

Test Probe Length

100 mm

Test Probe Diameter

1.0 mm

Dam-Sphere Diameter

35 mm

Handle Diameter

10 mm

Handle Length

100 mm

Calibrated Thrust

1N ± 0.1N (Built-in Force)

Standard Compliance

IEC 60529 / EN 60529 (Probe D)


Complete IP Testing Solutions

Beyond IP4X test probes, LIB Industry provides IP5X/IP6X dust and sand test chambers and complete IPX1–IPX9K water ingress testing equipment for comprehensive ingress protection testing.

Need a complete IP testing solution? Contact LIB Industry to discuss your requirements.
