Weatherometer Laboratory Testing Equipment(UV)

LIB weatherometer laboratory testing equipment (UV) combines UV light, spray, temperature and humidity,which provides a more realistic UV corrosion environment.

Wide bandwidth 290 ~ 400nm,UV lamps (8) - 40 W.High density and high precision UV light make UV aging test greatly accelerated.



Model: UV-660

Standard: ASTM G154, ISO 4892,ASTM D 4329 – 05, ASTM C1257, ASTM C1442, ASTM C1519, ASTM C793, ASTM D1148, ASTM D3424, ASTM D3451, ASTM D4101,  ASTM D4811, ASTM D904, GM 9125P, ISO 29664, ISO 4892-1 (EN) (DIN)




Xenon Arc Tester Features and Benefits

1. A variety of filters are available. For example, daylight filters are used to simulate sunny days, and UV cut-off filters can shield specific ultraviolet bands to meet different test needs.

2. It can meet many international standards such as ISO 105B-06 and ASTM G155-1, and the test results are widely recognized.

3. Precise control of irradiance and blackboard temperature. The irradiance can be controlled at 35~150W/m², and the blackboard temperature range is 35~85℃±2℃.

4. SUS 304 stainless steel, mirror surface, rust-proof to high and low temperature and moisture corrosion resistance.



Specifications of Xenon Arc Tester

Model

XL-S-500

Internal Dimension (mm)

500*600*700 mm

Overall Dimension (mm)

1000*1140*1920 mm

Chamber Type

Flat shelf

Irradiation Source

1 piece of 4500w water-cooled xenon arc lamp

Irradiance Range

35~150 W/㎡

Bandwidth Measurement

300nm~400nm (340nm or 420nm)

Chamber Temperature Range

Ambient ~ 100 ℃ ±2℃

Black Panel Temperature

BPT 35 ~ 85 ℃ ±2℃

Humidity Range

50% ~ 98% RH

Humidity Deviation

± 5% RH

Water Spray Cycle

1~9999H59M  (Adjustable)



Configuration of  Xenon Arc Tester



①Workroom

  • Xenon arc Lamp is located at the top, Average Lamp Life: 1600 hours, air cooling, water cooling two kinds of lamps are optional.

  • Stable strong light output, simulate full spectrum light.




②Spray system

The spray system simulates rainfall on demand, and the amount of water and the period are controllable to test the performance changes of the material under the combined action of moisture and light.


③ Air circulation system

Maintain air circulation and ensure that ambient conditions such as temperature, humidity and light are evenly distributed in the chamber.


④ Heating system

Ni-cr alloy electric heating element is adopted. The highest temperature can reach 100℃.


⑤Humidity system

Steam humidifier, humidity 50%~98% adjustable.


⑥ Control system

The controller can be programmed to display and record various parameters in real time, such as temperature, humidity, light intensity, test time, etc.


⑦ Refrigeration system

Mechanical refrigeration cycle, with heating system to control the temperature, fast cooling, stable efficiency.




LIB Team will send you specs and quote today.
